W5500 Chip New SPI to LAN Ethernet Converter Module

Description:

High speed SPI interface 80MHz

Hardware-TCPIP-protocol stack user built in, almost without understanding the complex network protocol knowledge

Supports up to 8 Socket

Support TCP, UDP, ICMP, IPv4, ARP, IGMP, PPPoE protocol

Integration of the data link layer, physical layer

Support the wakeup

Support high speed serial peripheral interface (SPI model 0, 3)

Internal 32K bytes receive buffer

The embedded 10BaseT/100BaseTX Ethernet physical layer (PHY)

Support auto negotiation (10/100-Based full duplex or half duplex)

Does not support the IP patch

The working voltage of 3.3V, I/O and 5V voltage signal

LED display (full duplex or half duplex, network connection, network speed,active)

Pin type package ultra small, convenient for embedded applications

Application of C sample project

Specification:

Power supply mode: 3.3V external power supply, current should be more than 200mA;

Control interface: The TTL level, 3.3V SPI interface;

PCB size: 23 * 25 mm;

Mechanical Dimensions: 28.5 * 23 * 2

Package Includes:

1 x W5500 Ethernet Module
